OEM - beeldscherm - LM270WF5 SLM1

LG LM260WF5 SLM1 scherm

Resolution

1920 X 1080

Brightness

250 cd/m2 (Typ.)

Viewing Angle

89/89/89/89 (Typ.)(CR>=10)

Contrast Ratio

1000:1 (Typ.) (TM)

Display Colors

16.7m 72% (CIE1931)

Pixel Format

RGB Vertical Stripe

Display Area

597.888 X 336.312(mm)

Display Mode

s-IPS, Normally Black , Transmissive

Lamp Type

WLED 14s4p 30k Hours Without Driver

Outline Size

617.1 X 361.3 X 14.75(mm)

Surface

Matte (Haze 25%)

Panel Weight

3.30/3.50kgs (Typ./Max.)

Response Time

14 (Typ.)(g to g)

Frequency

60Hz

Signal Interface

LVDS (2 ch 8-bit) 30 pins

Input Voltage

5.0v (Typ.)

Matte (Haze 25%)

Panel Weight

3.30/3.50kgs (Typ./Max.)

Response Time

14 (Typ.)(g to g)

Frequency

60Hz

Signal Interface

LVDS (2 ch 8-bit) 30 pins

Input Voltage

5.0v (Typ.)

Environment
